Monolithic Amplifier Design: The Denon AVR-X6800H AV receiver is built to last and delivers audiophile-grade sound thanks to its monolithic amplifier construction. The Denon AVR-X6800H features a powerful Class AB power amplifier section equipped with discrete custom-made high current power transistors (D.H.C.T) for high current capability. This discrete, monolithic amplifier design delivers optimum realism and stunning dynamic range. By using high current, high power discrete power devices and a monolithic amplifier layout, the Denon AV receiver is able to easily drive high quality speakers. The AV receiver's eleven channel Class AB amplifier is rated at 140 watts (into 8-ohm, @ 20-20kHz, with 0.05% THD, driving 2 channels) and will deliver reference class, room-filling sound with astonishing clarity, power, detail, and depth.
Amplifier Assignment: The AVR-X6800H's eleven discrete amplifier channels can be configured to accommodate your type of home theater setup. Its powerful DSP is even capable of up to 13.2 channel processing, allowing you to extend the system with an additional power amplifier.
- 13ch: Provides 13ch playback by assigning all eleven internal amplifiers to the receiver's main zone and using an external 2ch amplifier for either the Front or Height channels. Up to eleven speakers can be powered by the receiver's amplifier, while two speakers are powered by an external amplifier. This amplifier configuration is compatible with up to 13.2ch and 9.2.4ch applications.
- 11ch: Provides 11ch playback by assigning all eleven internal amplifiers to the receiver's Main Zone. Front, Center, Surround, Surround Back, Height 1, and Height 2 speakers can all be played back at the same time in the Main Zone. This amplifier configuration can support up to 7.2.4ch Dolby Atmos/DTS:X.
- 9ch Bi-Amp: Assigns all eleven amplifiers of the receiver to the Main Zone with the front speakers bi-amped. Up to nine total speakers are be connected at one time - including Front, Center, Surround, Surround Back and Height speakers. The receiver's Height 2 amplifier channels are assigned to bi-amp the front speakers. A bi-amplification connection uses two amplifiers for one speaker. One amplifier is connected to the woofer section of a loudspeaker while the other is connected to the combined midrange and tweeter section. With this arrangement each amplifier operates over a limited frequency range, making its job easier. This amplifier configuration can support up to 7.2.2ch Dolby Atmos/DTS:X.
- 9ch + Zone 2 or Zone 3: The receiver's eleven amplifier channels are assigned to power a 9ch speaker system in the Main Zone and stereo speakers in either Zone 2 or Zone 3 (not both). The Main Zone will consists of Front, Center, Surround, Surround Back and Height speakers. The receiver's Height 2 amplifier channels are assigned to power Zone 2. This amplifier configuration can support up to 7.2.2ch Dolby Atmos/DTS:X.
- 9ch + Zone2/3-Mono: Assigns nine of the amplifier channels of the AV receiver for 9ch playback in the Main Zone and one amplifier each to Zone 2 and Zone 3 for mono audio in each zone. The Main Zone will consist of Front, Center, Surround, Surround Back and Height speakers. The receiver's Height 2 amplifier channels are assigned to power both Zone 2 and Zone 3 for mono sound. This amplifier configuration can support up to 7.2.2ch Dolby Atmos/DTS:X.
- 9ch + Front B: Assigns nine amplifier channels of the receiver to the Main Zone for up to 9ch playback and two amplifier channels to power another pair of front speakers in the Main Zone for stereo playback only. This is useful when you want to have a dedicated pair of 2ch speakers, in addition to your home theater speakers. If you choose to play the Front A and Front B speakers at the same time, Front B will play the same exact audio source and audio signal as Front A without down-mixing. Up to eleven total speakers can be connected in the Main Zone - including Front, Center, Surround, Surround Back, Height, and Front B speakers. The receiver's Height 2 amplifier channels are assigned to power the Front B speakers. This amplifier configuration can support up to 7.2.2ch Dolby Atmos/DTS:X.
- 7ch Bi-Amp + Zone 2: Assigns nine amplifiers of the receiver to the Main Zone with the front speakers bi-amped and two amplifier channels assigned to Zone 2 to power a pair of speakers in another room. The 7ch speaker system will consists of Front, Center, Surround, and Surround Back. The receiver's Height channels are reassigned to bi-amp the front speakers and power Zone 2. The Surround Back speakers of the main zone can be re-assigned for up to 5.2.2ch Dolby Atmos/DTS:X.
- 7ch + Zone 2/3: Assigns seven amplifier channels to the Main Zone for 7ch playback and four amplifiers to Zone 2 and Zone 3 for stereo playback in each zone. The 7ch speaker system will consists of Front, Center, Surround, and Surround Back. The receiver's Height amplifier channels are reassigned to power both Zone 2 and Zone 3. The Height speakers of the main zone can be re-assigned for up to 5.2.2ch Dolby Atmos/DTS:X.
- 5.1ch Full Bi-Amp: In this mode you can bi-amp the front, center, and surround speakers for improved sound quality with bi-amp capable speakers in a traditional 5.1 layout. Dolby Atmos, DTS:X, AURO-3D not supported with this configuration. Zone 2 & Zone 3 are only available using pre-outs with separate amplifiers.
Advanced Sound Processing: The Denon AVR-X6800H AV receiver offers advanced sound processing so you can experience extraordinary sound quality from both music and movies.
- D.D.S.C (Dynamic Discrete Surround Circuit) HD 32-Bit DSP: Inherited from the Denon flagship AVR-X8500H, a sophisticated digital audio processing system (D.D.S.C) that incorporates two dual SHARC+ core 32-Bit DSP chips is adopted on the AVR-X6800H allowing up to 11-channel audio processing and decoding capability at ease.
- AL32 Processing: AL32 Processing Multi-channel provides ultra-high-resolution digital audio filtering and precision for all audio channels, to deliver a natural soundstage with enhanced imaging. You'll enjoy outstanding high-frequency detail, along with smooth midrange and accurate bass.
- 32-Bit/192kHz DACs: For optimum fidelity and the widest dynamic range with lowest distortion, the AVR-X6800H features advanced reference-class 32-bit/192kHz digital-to-analog converters (DACs) on all channels. This ensures consistent high fidelity and precise channel matching across all channels for the ultimate listening experience.
- Clock Jitter Reducer The AVR-X6800H is equipped with a ""Clock Jitter Reducer"" that is capable of reducing jitter and phase noise that negatively affect sound quality. The ""Clock Jitter Reducer"" provided with this unit improves the sound localization, reproducing a natural sound field that is closer to the original soundtrack.
Compatible Digital Audio Formats: The AV receiver supports the following stereo & multichannel digital audio formats through its HDMI jacks and optical/coax digital inputs.
| Digital Audio Connector | Audio Signal Type | Audio Signal Format |
| HDMI (7 Inputs/3 Outputs) | High Definition Audio Bitstream | Dolby Atmos, Dolby Digital Plus,Dolby TrueHD
DTS:X, DTS-HD Master Audio, DTS-HD High Resolution, DTS Express |
| Bitstream | Dolby Digital, Dolby Digital EX, DTS, DTS ES, DTS 96/24 |
| DSD | 2ch to 6ch (2.8MHz; 1-bit) |
| PCM | 2ch to 8ch (32-192kHz, 16/20/24-bit) |
| Optical/Coaxial (2 Optical Inputs/2 Coaxial Inputs) | Bitstream | Dolby Digital, Dolby Digital EX, DTS, DTS ES, DTS 96/24 |
| PCM | 2ch to 6ch, (32-96kHz, 16/20/24-bit) |
Immersive Surround Sound: The Denon AVR-X6800H AV receiver goes beyond regular surround with the latest immersive surround sound formats from Dolby Atmos, DTS:X, Front Wide, and AURO-3D. The AVR-X6800H offers 11-channels of amplification with support for up to 13.1 channel processing, allowing you to configure a 5.1.2, 5.1.4, 7.1.2, 7.1.4, 9.1.2, or 9.1.4* channel speaker system. A 9.1.4* channel speaker system will require an additional 2ch amplifier (sold separately).
- Dolby Atmos: Dolby Atmos surround sound technology dispenses with channel-based coding in favor of more advanced object-based coding, giving the soundtrack designer the ability to precisely place sounds anywhere in the 3-dimensional space. Now you can enjoy this same award-winning technology at home with the AVR-X6800H that lets you configure a Dolby Atmos speaker system for the ultimate home theater experience.
- Dolby Surround: Dolby Surround offers an enhanced cinema experience to your 2ch or multichannel movie soundtracks using your existing 5.1ch, 7.1ch, or Dolby Atmos speaker setup. Dolby Surround enhances audio definition by improving the spatial dimension and overall audio definition of movie soundtracks. It does this by using four distinct surround zones that provide greater control over the exact placement of each detail in a movie sound track, so audio can be matched more accurately to the video on screen; this means more depth and greater realism for your movies. As a result, individual sounds are clearer and more distinct. It also improves the surround sound experience across the entire theater by widening the listening ""sweet spot"".
- Dolby Atmos Height Virtualization: Dolby Atmos Height Virtualization provides immersive audio without height-channel or overhead speakers, creating virtual height effects in a 5.1ch, 7.1ch or 2.1ch speaker arrangement. Dolby Atmos Height Virtualization applies carefully designed ""height-cue"" filters to the overhead audio components of your content's soundtrack before they are mixed into your loudspeakers to create the sensation of sound above you.
- DTS:X: The latest immersive surround sound system, DTS:X features object-based audio coding that lets the soundtrack designer place sonic elements anywhere in the 3D acoustic soundspace, and provides for overhead speakers to deliver a stunning surround sound experience. Along with DTS:X decoding, the AVR-X6800H features DTS-HD Master Audio decoding and other DTS audio technologies.
- DTS:X Pro: The AVR-X6800H will support DTX:S Pro. Get up to 13.2 channels of audio processing with DTS:X Pro to enjoy a full surround sound in great detail. You will need an additional external stereo amplifier connected to the AVR-X6800H to drive the additional two channels.
- DTS Neural:X: DTS Neural:X is an advanced spatial remapping technology from DTS, which provides a fully immersive output for all types of source content; this includes DTS bitstreams and non-encoded (PCM) data. DTS Neural:X delivers a thrilling sense of immersive sound to your speaker layout regardless of the original source format.
- DTS Virtual:X: DTS Virtual:X bridges the gap between DTS:X and the reality of so many consumers' homes, allowing you to enjoy multi-dimensional sound regardless of room size, layout, or speaker configuration. DTS Virtual:X can be used with any content (from 2ch to 7.1.4ch soundtracks), while delivering virtual height & virtual surround processing based on psychoacoustics (not reflective surfaces).
- AURO-3D: This receiver is equipped with an Auro-3D decoder. With Auro-3D, Front Height, Surround Height and Top Surround are added to a conventional 5.1-channel system to achieve a natural and realistic soundfield that is three-dimensional and fully immersive. You will be able to fully enjoy Auro-3D playback if you properly place the speakers for Auro-3D. Auro-3D does not support a Dolby Atmos configuration using Top Front, Top Middle, Top Rear, or any Dolby Atmos Enabled speakers. But it is possible to support both an Auro-3D and Dolby Atmos by adding Front Height and Rear Height speakers to a 5.1 configuration. For an optimum Auro-3D experience Surround Height speakers are strongly recommended.
- Front Channel Wide: With Front Wide channel support, you can add two front wide speakers with both Dolby and DTS to create a more seamless front surround stage with up to 9.1.2 or 9.1.4 speaker configurations. 9.1.4 setup requires an additional two-channel stereo amplifier connected to the AVR-X6800H.
Audyssey Suite with Dual Presets: The AVR-X6800H features the Audyssey suite of powerful DSP features - including MultEQ XT32, Sub EQ HT, LFC (Low Frequency Containment), Dynamic Volume, and Dynamic EQ. The newly adopted Dual Audyssey Preset function allows you to store and instantly switch between two Audyssey configurations. For example, you can store both the Audyssey calibration result straight from the receiver and a customized MultEQ curve or frequency range made through the Audyssey MultEQ editor app on the receiver simultaneously, allowing you to easily compare differences and select your preference. You can also perform Audyssey measurements for two different speaker settings, including 2.0 for music listening and 5.1.4 for movie surround.
- MultEQ XT32: Via the supplied measuring microphone, Audyssey MultEQ32 measures all the speakers in your home theater during setup, including the subwoofer, and then generates multiple high precision DSP room acoustic correction filters, which together provide smoothest and most natural tonal balance, regardless of the brand or model of the various speakers. Audyssey MultEQ32 incorporates more than ten thousand individual control points allowing finer details of the room's problems to be captured and corrected. Up to eight listening positions can be measured, configured, and recorded. MultEQ XT32 compensates for both time and frequency characteristics of the listening area based on ""Audyssey Setup"" measurement results. Selection is done from three types of compensation curves - Reference (default and recommended, L/R Bypass, Flat, and Off).
- Sub EQ HT: Audyssey Sub EQ HT provides individual DSP tailoring of each subwoofer in a dual subwoofer setup, for deeper bass with improved definition, compared to a single subwoofer configuration.
- LFC (Low Frequency Containment): Audyssey Low Frequency Containment uses advanced psychoacoustic algorithms to deliver a full range tonal balance, including deep bass, but without disturbing close-by neighbors or family members in other rooms, and features a multi-step adjustment that lets you dial in the amount of containment to your preference.
- Dynamic Volume: Audyssey Dynamic Volume features advanced psycho-acoustic processing to deliver clear dialog and wide range sound at reduced volume levels so that you can enjoy theater-level clarity at whatever listening level you choose.
- Dynamic EQ: Audyssey Dynamic EQ also features advanced DSP processing to deliver full range wide-band response, even at reduced volume levels. Dynamic EQ Reference Level Offset provides three offsets from the film level reference (5 dB, 10 dB, and 15 dB) that can be selected when the mix level of the content is not within the standard.
Note: You have the option to upgrade to Dirac Live (fees will apply); an advanced state-of-the-art digital room correction software that utilizes your Windows PC or Mac computer and a 3rd party USB microphone (sold separately) to analyze your speakers and listening room for optimum speaker performance and the removal of unwanted sound colorations introduced by the room. The result is substantially improved sound-staging, clarity, and voice intelligibility.
Listening Modes: The Denon AVR-X6800H features a variety of Listening modes to choose from, so you can enjoy your movie or music soundtrack the way you want to hear it.
- Auto Detection: In Auto Mode, the Listening Mode switches automatically to the corresponding type of audio input signal (Dolby Digital, Dolby TrueHD, Dolby Digital Plus, DTS, DTS-HD, or multichannel PCM) that is detected. If the input signal is analog or PCM (2-channel), stereo playback is used.
- Denon Original Sound: Denon's Original Listening Modes, combined with Dolby Digital/DTS processing, produce more realistic, powerful sound effects for your movie and music sound tracks based on the type of content and your home theater setup. Choose between Rock Arena, Jazz Club, Matrix, Video Game, Mono Movie, Multichannel Stereo, or Virtual (surround from only front speakers or headphones).
- Stereo Playback: Sound is output from the front left and right speakers, as well as the powered subwoofer. If multichannel signals are input, they are mixed down to 2-channel audio. The tone settings can be adjusted.
- Direct Modes: The Denon AVR-X6800H offers two Direct Listening Modes which bypass the receiver's tone & DSP processing for higher sound quality performance. Direct Mode provides playback of 2ch or Multichannel audio in its original form, without any surround or tone processing. Pure Direct Mode goes a step further by turning off the receiver's display and analog video circuitry to minimize the possibility of any noise being added to the audio signal.
Audio Enhancements: The Denon AVR-X6800H receiver provides various audio enhancements to deliver a high-quality listening experience every time.
- CINEMA EQ (Cinema Equalizer): The Cinema EQ function gently decreases the level of the extreme high frequencies, compensating for overly-bright sounding motion picture soundtracks. Select this function if the sound from the front speakers is too bright. This function only works in the Dolby Digital & DTS modes.
- Compressed Audio Restorer: Compressed audio formats such as MP3, WMA (Windows Media Audio), and MPEG-4 AAC reduce the amount of data by eliminating signal components that are hard for the human ear to hear. The Restorer function generates the signals eliminated upon compression, restoring the sound to conditions near those of the original sound before compression. It also corrects the sense of volume of the bass to obtain richer sound with compressed audio signals.
- Dynamic Range Compression (DRC): Motion picture soundtracks have tremendous dynamic range (the contrast between very soft and very loud sounds). For listening late at night, or whenever the maximum sound level is lower than usual, Compressing the dynamic range allows you to hear all of the sounds in the soundtrack with reduced dynamic range. DRC works when playing program sources recorded in Dolby Digital or DTS.
- Room Size: The receiver's audio output can be set to simulate the acoustics of a Small, Medium Small, Medium (default), Medium Large, or Large room environment. This setting is not an indication of the actual size of your listening area.
- Center Spread & Dialog Control: Center Spread expands the center channel signal to left and right front speakers to create a wider frontal audio image for the listener, when in Dolby Surround mode. Dialog Control adjusts the volume of dialog in movies and vocals in music so they can be heard more easily, when in DTS:X mode.
- LFE + Main: The LFE + Main setting boosts the bass sound by feeding the low-frequency signal to both the loudspeakers and the powered subwoofer, regardless of audio format or listening mode.
Volume & Level Settings: The AVR-X6800H offers the following volume & level settings.
- Volume Settings: You can choose to display an Absolute volume scale (0-98) or Relative volume scale (-79.5 to 18dB). You can also set a maximum volume level of 0 (80), -10 (70), or -20 (60) dB to limit the receiver's total volume output. In addition, you can define the volume setting that is active when the power is turned on; select ""Mute"", -79 to +18dB (1-98), or Last. These settings can be set independently for the Main Zone, Zone 2, and Zone 3.
- Mute Level: You can set the amount of attenuation for the audio muting circuit; -40dB or -20dB below current volume, or full mute (sound turned off entirely). The Mute Level can be set independently for the Main Zone, Zone 2, and Zone 3.
- Channel, Center, & Subwoofer Level: The volume level (-12 to +12dB) of each channel can be changed while listening to audio for each input source. You can also adjust the center channel volume level (-12 to +12dB) independently from the channel level to clarify the dialog for all sources. In addition, you can adjust the subwoofer channel volume level (-12 to +12dB) independently from the channel level to emphasize low frequencies for all input sources.
- Source Level: This function adjusts the playback level of the currently selected input source's audio input. Use this feature if there are differences in the input volume levels between different sources. You can correct the playback level of the audio input from -12 to +12dB.
eARC (Enhanced Audio Return Channel): This feature of the AV receiver's main HDMI monitor output allows audio to be sent from your compatible TV to the receiver through the same HDMI cable already being used to send audio and video to your TV. This eliminates the need for extra cables connected to your television. eARC (Enhanced Audio Return Channel) will support uncompressed audio formats like Dolby TrueHD, Dolby Atmos, DTS:X, & DTS HD Master Audio - where as the previous ARC (Audio Return Channel) was limited to only Dolby Digital, Dolby Digital Plus, DTS, DTS HD, and PCM.
Note: Supported content will be dependent on whether your TV features a HDMI eARC or ARC jack.
Pre-Amplifier Mode with 13.4ch Pre-Outs: With Pre-Amplifier Mode, the Denon AVR-X6800H can work as an AV pre-processor with the latest HDMI connectivity to upgrade and modernize your AV separate system. Pre-Amplifier Mode provides a cleaner signal path and more tolerance in clipping level by disconnecting the AV receiver's internal amplifiers, when the receiver is used as an AV processor and all speakers are powered by external amplifiers. The AVR-X6800H receiver features 13.2ch variable pre-amp outputs (Front L/R, Center, Surround L/R, Surround Back L/R, Height 1 L/R, Height 2 L/R, Front Wide, and Quad Subs) for connection of external power amplifiers to create a 7.4.6ch or 9.4.4ch Dolby Atmos/DTS:X sound system.. For compatibility with multiple subwoofer home theater systems, the AVR-X6800H features four discrete subwoofer outputs.
Note: You can also utilize the AV receiver's pre-outs and speaker outputs simultaneously by not engaging Pre-Amplifier mode.
Color-Coded Speaker Terminals: The receiver has binding-post terminals for all speaker connections. The binding-post terminals can accept bare wire, pin connectors, and banana plugs (single/dual). The receiver will accept speaker impedances of 4 to 16-ohm. The AV receiver comes with color-coded labels to easily identify which channel a speaker cable should be connected to. Since the speaker cables have labels in the same colors as the connectors on the AVR-X6800H's rear panel, there's no longer any confusion about which terminals they should be connected to.
Headphone Jack: When headphones are plugged into the full-size 1/4"" jack on the front panel, all the speaker outputs and pre-outs are automatically muted.
Phono Input: The Denon AVR-X6800H is outfitted with a Phono input (MM), so you can connect your turntable and listen to your vinyl records with high-quality sound.
Video Section
HDMI 2.1: Featuring seven HDMI inputs and three HDMI outputs, the AVR-X6800H incorporates an advanced video section that features some of the latest HDMI 2.1 specifications; including support for 8K/60Hz and 4K/120 Hz video pass-through (up to 40Gbps), HDCP 2.3 compatibility, BT.2020 Wide Color Gamut, and 4:4:4 Pure Color sub-sampling. Use a premium High Speed 18Gbps HDMI cable for the best 4K/HDR performance. Use an Ultra High Speed 48Gbps HDMI cable to enjoy 8K video.
- 4K/120 Hz + 8K/60Hz Pass-Through: All of the AVR-X6800H's HDMI inputs, as well as the Main and Monitor 2 HDMI outputs support up to 8K (7680 x 4320) video @ 60 frames per second, as well as 4K video @ 120 frames per second (both up to 40Gbps). The Zone 2 HDMI output is limited to 4K (3840x2160 pixels) video @ 60 frames per second. In addition, the the HDMI inputs and outputs will pass a 1080p/i, 720p, and 480p/i video signal.
- HDCP 2.3 Compliant: All of the AV receiver's HDMI inputs and outputs support HDCP 2.3, which fully complies with the latest copyright protection standard for 4K/HDR video transmission.
- 4:4:4 Color Subsampling: The HDMI inputs and monitor outputs support RGB, YCbCr 4:4:4, YCbCr 4:2:2, and YCbCr 4:2:0 color subsampling (pixel depth and frame rate will vary). With 4:4:4 color subsampling, luminance (brightness) and chroma (color) are sampled at the same rate; resulting in an RGB color palette as big as the video sampling rate for a video image with more colors, plus greater color accuracy and detail.
- Wide Color Gamut (BT.2020): The BT.2020 color standard delivers a much wider color gamut and represents about 75% of the total visual color spectrum, while the current Rec. 709 color standard selected as the color space for HDTVs and early generation 4K Ultra HDTVs covers only 35% of the total visual color spectrum.
Notes: Make sure to et the AV receiver's ""4K/8K Signal Format"" to ""8K Enhanced"" in the menu to enjoy 8K/60Hz or 4K/120Hz video.
Dynamic HDR: HDR provides enhanced picture quality by simultaneously enabling greater detail for both the dark and bright parts of an image. HDR reproduces a greater dynamic range of luminosity or brightness levels, creating greater contrast. This increased contrast reveals the subtle nuances of the image, from detailed blacks and shadows to the brightest whites and colors, plus greater depth. Dynamic HDR enables a noticeable progression in overall video image quality from SDR to static HDR, and now static HDR to dynamic HDR. Dynamic HDR support ensures every moment of a video is displayed at its ideal values for depth, detail, brightness, contrast, and wider color gamuts on a scene-by-scene or even a frame-by-frame basis. Dynamic HDR enhanced content is available for movies, videos, TV shows, video and PC games and VR.
- HDR10: HDR10 is an open standard and currently the most popular HDR format on the market. It uses static metadata at the start of a movie to tell the receiver and your TV that the video content is encoded using HDR.
- HDR10+: HDR10+ is a new open standard that leverages dynamic metadata to produce enhanced contrast and colors on an expanded range of televisions. HDR10+ incorporates dynamic metadata that allows the adjustment of brightness levels on a scene-by-scene or even frame-by-frame basis. By applying individualized tone mapping to each scene, HDR10+ delivers an incredible viewing experience. The picture quality offers an enhanced visual experience with more detailed expressions, brighter shadow areas and more accurate color renderings that stay true to the creator's original intent.
- Hybrid-Log Gamma: HLG (Hybrid-Log Gamma) is primarily designed for live video feed and over-the-air broadcasts. It uses no pre-encoded metadata and is backwards compatible with SDR. HLG's native compatibility allows much of today's existing SDR infrastructure to be re-used for HDR in the future.
- Dolby Vision: Unlike HDR 10 which contains static metadata and HLG which uses no metadata, Dolby Vision uses dynamic metadata technology which sets individual color and brightness levels for each and every scene. Dolby works directly with filmmakers at major Hollywood studios to create superior HDR video masters of blockbuster movies.
4K/8K HDMI Video Upscaling: The Denon AV receiver offers HDMI video upscaling (up to 4K or 8K Ultra HD) thanks to its NatureVue video processor by Analog Devices. This sophisticated video processor provides upscaling of 1080p high definition HDMI connected sources to 4K or 8K Ultra HD; as well as 4K Video sources to 8K picture quality. The AV receiver only upscales HDMI input sources through the receiver's main HDMI output (not the second HDMI output or Zone 2 HDMI output).
- It does not upscale 480i, 480p, 720p, or 1080i video from HDMI inputs.
- It does not upscale 480i or any other video resolutions from composite or component video inputs.
Three HDMI Outputs: The AV receiver is equipped with a total of three HDMI outputs. The Main HDMI output and Monitor 2 HDMI output are in parallel and distribute the same HDMI input signal (up to 8K) simultaneously to two separate displays, while the Zone 2 HDMI output is discrete and allows you to play a different HDMI audio/video source (up to 4K) in another zone (Zone 2).
- All seven HDMI inputs are supported by all three HDMI outputs (Main, Monitor 2, and Zone 2). .
- The receiver's composite and component video inputs can only be output via the Main HDMI output (not supported by the Monitor 2 and Zone HDMI outputs).
Optimized Gaming: Showcased in the AVR-X6800H are new HDMI features like Variable Refresh Rate (VRR), Quick Frame Transport (QFT), and Auto Low Latency Mode (ALLM) - which reduce or eliminate lag and frame tearing to offer a smoother, lag-free gaming experience.
- Variable Refresh Rate (VRR): Support for Variable Refresh Rate (VRR) allows the TV to adapt to certain Game console's frame rate. This helps to reduce or eliminate lag, stutter and frame tearing for more fluid and better detailed gameplay.
- Auto Low Latency Mode (ALLM): The receiver will enter ALLM (Auto Low Latency Mode) when it detects a gaming signal from a compatible device (such as a Xbox One) and allows for a smooth, lag-free gaming experience. During ALLM, the receiver disables the i/p scaler and Auto Lip Sync function.
- Quick Frame Transport (QFT): Quick Frame Transport (QFT) transmits each frame at a higher rate to decrease ""display latency"", which is the amount of time between a frame being ready for transmission in the GPU and that frame being completely displayed. Enjoy reduced latency for smoother, tear-free entertainment experience.
Other HDMI Features: The Denon AVR-X6800H AV receiver's HDMI connectivity also offers 3D video pass-through and auto LipSync function.
- 3D Ready: The AVR-X6800H AV receiver supports 3D video pass-through (720p/1080p only) from connected 3D-compatible Blu-ray, games and broadcast devices to 3D-compatible HDTVs (all 3D components must be connected via HDMI). Special eyewear will be required for viewing 3D content.
- LipSync: This function adjusts the delay between audio and video output. You can do this manually or have the receiver set the LipSync function automatically. When connected to a TV via HDMI the receiver automatically adjusts audio output timing, if the TV supports an automatic LipSync function. You can also manually delay the sound output up to 500ms to synchronize it with the video image.
HDMI Standby Pass-Through: When the AV receiver is in ""Standby"" mode and the HDMI Standby Pass-Through function is enabled, both audio/video streams from the receivers HDMI input will be output to your television, via the AV receiver's HDMI monitor output. Once the receiver is turned ""On"", only video will pass through the monitor output to your TV and the audio is directed to the receiver's speaker outputs.
- HDMI Input: Selects the HDMI Input for which the HDMI Standby Pass-Through function is enabled.
- Last: The HDMI Standby-Through function is activated on the input source selected at the time of setting the AV receiver to the ""Standby"" mode.
- Off: The HDMI Standby Pass-Through function is disabled.
Analog Video Inputs: The receiver features two composite video inputs and one component video input which all support 480i video only (not compatible with 480p, 720, or 1080i/p). There are no composite or component video outputs. The composite and component video input signals are output via the AV receiver's Main HDMI output and upscaled to 4K or 8K. The Monitor 2 HDMI out and Zone 2 HDMI out will not output a video signal from the receiver's composite or component video inputs.
Advanced ISFccc Video Calibration: The AVR-X6800H is certified by the Imaging Science Foundation to deliver top video quality, and the unit also features advanced ISFccc video calibration controls that allow for precision fine-tuning of the connected HDTV, even if it's not an ISF certified set. You can choose from a variety of Picture Modes - Standard, Movie, Vivid, Streaming, ISF Day, ISF Night, Custom, or Off. The Custom mode lets you manually adjust Contrast, Brightness, Saturation, Noise Reduction, and Enhancer (sharpness).
Video Modes: You can set the video processing method to match the type of video content. Choose from Movie, Game, Auto, or Bypass. The Movie mode performs image processing that is suitable for watching movies with smooth action scenes, while the Game mode minimizes video lag and delay for better gaming performance. The Auto mode processes video automatically based on the HDMI content information, while Bypass mode removes all video processing from the HDMI video path.
Video Select Function: This receiver can display video from a different source on your connected TV during audio playback from CD (analog input only), Tuner, HEOS, or Phono.
Network & Tuner Functions
Wired or Wireless Network Connection: The Denon AVR-X6800H offers a wired or wireless network connection. Either network connection gives the receiver access to HEOS music apps (like Pandora, Amazon, or Tidal), TuneIn Internet Radio, Spotify Connect, your music library on your Apple iOS or Android device, as well as music content on your Windows PC or DLNA music server.
- Ethernet Jack: The Denon AVR-X6800H receiver is fitted with a RJ-45 Ethernet (LAN) port to make a wired connection from the receiver to your home network.
- Built-in WiFi: The receiver also offers built-in WiFi (IEEE 802.11ac; 2.4/5GHz) for a wireless network connection; WPS, WEP, WPA-PSK (TKIP), WPA-PSK (AES), WPA2-PSK (AES) security protection is supported. Wireless network setup can be done via WPS button, Access Point Scan, Manual Setting, PIN Code, or even through your Apple iOS device (7.0+).
TuneIn Internet Radio: The Denon AVR-X6800H includes access to more than 100,000 free internet radio streams from all corners of the globe via the built-in TuneIn online music service. Simply select TuneIn from the receiver's on-screen menu using the included remote and browse among the 100,000 stations neatly organized into popular categories and select a station that appeals to you.
Spotify Connect: If you subscribe to Spotify and have the Spotify App on your Apple iOS or Android mobile device, you can stream Spotify to the Denon AV receiver. Spotify is a digital music service that gives you on-demand access to one of the largest music libraries in the world (over 15 million tracks and counting). Spotify makes it easier than ever to discover, manage, and share music with your friends. You can browse music by artist, album, track, or most popular; and create your own music library with customized playlists.
HEOS Music Apps: With built-in HEOS technology and the HEOS app (for Apple iOS and Android OS) on your compatible Apple iOS or Android mobile device, you'll be able to stream a wide variety of online music services (fees may apply), plus the music library of your mobile device through the Denon AV receiver.
- Online Music Services: Using the HEOS app, you'll be able to stream your favorite online music services like Amazon Music (including HD), Pandora, TIDAL, iHeart Radio, SiriusXM, Napster, TuneIn, & Spotify (some services will require a paid subscription, purchases, and/or other fees). The HEOS app on your Apple iOS or Android device will serve as the controller for these apps and provide song/artist information with Album Art. You can create a ""Favorite"" station list, so you can quickly access your favorite internet radio stations and online music channels.
- Mobile Device Streaming: Using the HEOS app on your Apple iOS or Android mobile device, you are able to stream your device's music library to the Denon AV receiver. You'll be able to browse your music library by Artist, Album, Genre, and Song; control music playback functions like Play/Pause and Previous/Next Track; and view song/artist info with Album Art from the app on your compatible mobile device. You can even type in an artist name or song title to find music in your mobile device's library.
Notes:
- Prior to using the HEOS system, you'll need to setup up your free HEOS account. Your HEOS account remembers all your settings and preferences such as all your music service logins and HEOS playlists. When you'd like to add multiple smartphone or tablet controllers to your system, you only need to sign in to each new device with your HEOS user name and password. Instantly all your music services and HEOS playlists are available in the new controller too.
- If you prefer, HEOS supports multiple accounts in a single household. This way, each family member can enjoy their own personalized Pandora, Spotify, or other online music account settings and still share all the same speakers in the home.
Spatial 3D Audio: The Denon AVR-X6800H offers Spatial 3D Audio with support for 360 Reality Audio and Dolby Atmos Music for a truly immersive music listening experience. To enjoy 360 Reality Audio or Dolby Atmos Music, the AVR-X6800H needs a wired or wireless network connection, a compatible streaming online music service (such a Amazon Music, Tidal, and Apple Music) via HEOS or Apple AirPlay 2, and a 5.1.2ch to 9.1.4ch speaker setup.
- 360 Reality Audio: Immerse yourself in sound all around you with 360 Reality Audio; as real as if you are there at a live concert or with the artist recording in a studio - music has never been so immersive and so real. Because 360 Reality Audio tracks incorporate three-dimensional sound location data, they're able to deliver the ultimate in ambient room-filling sound. You'll need to subscribe to a 360 Reality Audio music streaming service such as Amazon Music Unlimited or Tidal via HEOS to enjoy this immersive music experience.
- Dolby Atmos Music: Dolby Atmos goes beyond the ordinary listening experience and puts you inside your music in a three-dimensional (3D) way, revealing every detail of the music with unparalleled clarity and depth. While audio mixed in stereo is limited to left and right channels with elements localized within the horizontal plane, Dolby Atmos allow creators to place individual sounds all around you in 3D space for a more immersive and realistic listening experience. Dolby Atmos Music is supported by the following online music services, such as Amazon Music Unlimited and Tidal HiFi Plus via HEOS or Apple Music via AirPlay 2.
Note: Amazon Music Unlimited, Tidal, and Apple Music all require a paid subscription.
DLNA 1.5 Certified: The AVR-X6800H is DLNA (Digital Living Network Alliance) 1.5 and Windows 7/8 compliant for audio and photo networking. This means it's easier for you to access and enjoy digital music and still-images (JPEG) stored on your Windows PC. You can use your PC to play high-bit rate music content through the A/V receiver and view still-images on your connected TV, or use the AVR-X6800H's remote control to browse music & photo files on your hard drive. The receiver also supports ID3-Tag (ver.2) and META tag information; so song title, artist name, and album name can be displayed the unit's front-panel display or on-screen menu. In addition the unit will display Album Art on a connected television. The Denon AVR-X6800H supports the following audio formats, sampling frequencies, and bit rates via its wired network connection.
| Resolution | Compatible Audio Formats | Sampling Frequencies | Bit-Rate/Bit-Depth | Extension |
| Hi-Res | WAV (PCM) | 32/44.1/48/88.2/96/176.4/192kHz | 16/24-bit | .wav |
| FLAC (Free Lossless Audio Codec) | 16/24-bit | .flac |
| ALAC (Apple Lossless Audio Codec) | 16/24-bit | .m4A |
| DSD | 2.8/5.6 MHz | 1-bit | .dsf/.dff |
| Compressed | MP3 (MPEG-1 Audio Layer-3) | 32/44.1/48 kHz | 32-320 kbps | .mp3 |
| WMA (Windows Media Audio) | 48-192 kbps | .wma |
| AAC (MPEG-4) | 16-320kbps | .aac/.m4a |
Note: Your computer must meet the following system requirements - Windows Media Player Network Sharing Service or Windows Media DRM10. Album Art is only displayed when using Windows Media Player (ver.11/12).
Roon Tested: Roon is a feature rich music library and playback application that compiles all the music files available to your network and makes them easily available to play on the Denon receiver and any other Roon enabled audio devices. Roon manages digital music files (including FLAC, WAV, AIFF, ALAC, and DSD) collected on hard drives and networked storage devices. It can also integrate your iTunes library, and optionally merge with the Tidal and Qobuz music streaming services. Roon software can be installed on your Windows or Mac computer, while a Roon Remote app is available for Apple iOS 11.0+ and Android OS 5.0+). When you access the Roon software or remote app, it will display your complete audio library together with its metadata and artwork along with the available Denon receiver and other Roon enabled devices. Simply select the music you wish to play and the Denon receiver or Roon device in which you want to hear it on.
- To use Roon you will need a Roon Server running on the same network as the Denon receiver. The Roon Server is media software that runs on your computer, NAS, or component (like Nucleus or ROCK - sold separately), located on the network within your home.
- Make sure your Denon product has the latest firmware/software update installed.
AM/FM Tuner: The Denon AV receiver features a built-in AM/FM tuner with 56 station auto-preset memory tuning. You can also set your presets manually. You can create an 8-character name for each preset station. You can even directly enter a station number using the receiver's on-screen menu and remote control.
AirPlay/Bluetooth/USB Integration
AirPlay 2 with Siri: AirPlay 2 is an advanced and easy-to-use wireless multiroom audio platform for iTunes, Apple Music, and other compatible Apple iOS apps. With AirPlay 2 you can play any audio from your Apple iOS device (running iOS 11.4 or later) or Mac computer (running OS X 10.13.2) on the AV receiver and other compatible AirPlay 2 speakers throughout your home. You can choose to play audio in one room, play the same audio in grouped rooms, or play the same audio in every room. If you are an Apple Music subscriber, you can even play different music in different rooms (you can control and group directly from Apple's Music App and Home app on your Apple iOS device). You'll be able to ask Siri-enabled devices (like your Apple iPhone, iPad, or Watch) to control playback of your Apple Music content on the AV receiver. With AirPlay 2, you also get to see song/artist information and album art via the receiver's on-screen menu (via HDMI). You can even watch videos and movies from YouTube and Netflix on your compatible Apple iOS device or Mac computer with perfectly synced audio on the AV receiver.
Built-in Bluetooth: The Denon AVR-X6800H is equipped with built-in Bluetooth (version 4.2) for wireless communication between Bluetooth-enabled audio source devices and headphones. The AVR-X6800H can act as a Bluetooth receiver in order to wirelessly stream music from an audio device, or a Bluetooth transmitter in order to wirelessly stream music to a set of BT-enabled headphones. The receiver's Bluetooth wireless range is approximately 98.4'.
- Bluetooth Receiver Mode: In BT Receiver mode, you'll be able to wirelessly stream stored music, music apps, and other audio content from your Bluetooth-enabled source device (such as your smartphone, tablet, computer, or laptop) to the Denon receiver. The receiver supports the Bluetooth SBC codec only. You will also be able to control basic playback functions (Play/Pause, FF/RW, Skip) using the receiver's remote control. Advanced music operation will still need to be handled from your Bluetooth-enable device. There is no song/artist information display on the receiver or connected TV; continue to use your Bluetooth device's screen to view song/artist info. Up to eight Bluetooth source devices can be remembered by the AVR-X6800H, so family members as well as friends can enjoy their favorite tracks (only one device can be used at a time). The receiver can even be setup to automatically re-connect with previously paired devices, as well as turn on automatically when you start streaming audio from a Bluetooth source device.
- Bluetooth Transmitter Mode: The Denon AVR-X6800H can also act as a Bluetooth transmitter and stream its non-Bluetooth audio sources (HDMI, Network, USB, Analog, Optical/Coax Digital, & AM/FM tuner) out to most any Bluetooth-enabled headphone set. You can even have the same source playing from the main speakers and a Bluetooth headphone simultaneously (with little noticeable delay). Volume control of your Bluetooth headphones will be controlled via the Bluetooth device and not the receiver. Up to eight headphones can be paired with the receiver, but only one set of headphones can be connected and used at a time.
Notes:
- You cannot use the Bluetooth Transmitter and Receiver modes simultaneously. The Bluetooth Transmitter mode is not available when the receiver's current source input is set to Bluetooth and vice-versa; Bluetooth Receiver mode is not available when the Bluetooth setting ""Transmitter"" is set to ON.
- Selecting a Bluetooth input source in any Zone will terminate the connection between the Denon receiver and Bluetooth headphones.
- You cannot connect Bluetooth headphones when the Denon receiver is grouped within the HEOS app. Remove the receiver from the group to enable Bluetooth headphones connection.
Front-Panel USB Port: This AV receiver is equipped with a front-panel USB (type-A) port that allows you to enjoy a variety of music files from a USB mass storage class memory device; such as a USB thumbdrive or portable digital audio player. Compatible USB storage devices must be formatted in FAT 16 or FAT32. The unit can recognize up to 500 folders/5,000 files. You can use the receiver's on-screen menu (via HDMI) and remote control to navigate your stored music files on your connected USB memory device. Song/artist information will display on your HDMI-connected TV and the receivers front-panel display. USB portable audio devices that can be charged via USB will be charged when plugged into the AV receiver's USB port (5V/1A); even in standby mode.
| Resolution | Compatible Audio Formats | Sampling Frequencies | Bit rate | Extension |
| Hi-Res | WAV (PCM) | 32/44.1/48/88.2/96/176.4/192 kHz | 16/24-bit | .wav |
| FLAC (Free Lossless Audio Codec) | 16/24-bit | .flac |
| ALAC (Apple Lossless Audio Codec) | 16/24-bit | .m4A |
| DSD | 2.8/5.6 MHz | 1-bit | .dsf/.dff |
| Compressed | MP3 (MPEG-1 Audio Layer-3) | 32/44.1/48 kHz | 32-320 kbps | .mp3 |
| WMA (Windows Media Audio) | 48-192 kbps | .wma |
| AAC (MPEG-4) | 16-320 kbps | .aac/.m4a |
Note: The receiver's USB port is not compatible with Apple iOS and Android devices, USB hubs, or card-readers.
Multiroom Audio/Video Playback
HDMI Zone 2: The AVR-X6800H also incorporates multi-zone HDMI audio/video distribution for Zone 2 with the inclusion of its HDMI matrix switching functionality. The receiver can send two different HDMI audio/video feeds to two displays at the same time directly from the receiver. The HDMI Zone 2 supports up to 4K video and 2ch PCM audio from the HDMI input source selected. Volume of HDMI Zone 2 is controlled from the TV or additional receiver in Zone 2.
- Composite and component video inputs cannot be output via HDMI Zone 2.
- HDMI Zone 2 does not support 8K video (limited to 4K) and does not offer HDMI upscaling.
- HDMI Zone 2 does not support multichannel audio (limited to 2ch stereo).
- If the receiver's Main Zone and HDMI Zone 2 are set to the same HDMI input source, the Main Zone audio will be mixed down to 2-channel audio.
Zone 2 (Audio Only): Zone 2 allows stereo audio playback of another source connected to the receiver in another room of your home via RCA line-level output or speaker-level output, as well as composite or component video. When using the AVR-X6800H to power speakers in a second room of your home, the main zone is restricted to 9.4-channels. When using the receiver's line output terminals for the second room you need an additional amplifier to power your Zone 2 speakers; the main Zone of the receiver remains 11.4-channel. The volume of Zone 2 can be controlled by the Denon receiver using either configuration or from your add-on amplifier when using the line-output.
- Compatible Sources:
- HDMI audio (2ch PCM only)
- Optical/Coaxial digital inputs (2ch PCM only)
- Analog audio/video (including Composite, Component, & Phono)
- AM/FM Tuner (cannot select different stations for each zone)
- USB & Bluetooth Audio (cannot select USB & Bluetooth in separate zones)
- HEOS Music Apps (including Pandora, Tidal, Amazon, and more); cannot select different HEOS music apps for each zone
- Network Sources (including TuneIn Internet Radio, Spotify Connect, AirPlay, & DLNA); cannot select two different network sources for Zone 1 and Zone 2
Incompatible Sources: - HDMI video
- Composite & Component video
- DSD audio files
Zone 3 (Audio Only): Zone 3 allows you to play a different stereo audio source connected to the receiver in a third room of your house. Zone 3 features pre-outs or speaker outputs, so you can use this amp or a separate amp to power speakers in another room. When using the AVR-X6800H to power speakers in a second and third room of your home, Zone 2 and 3 are limited to mono playback, while the Main Zone is limited to 9.4 channels. When using the receiver's pre-outs for the 2nd & 3rd Zone, you need additional amplifiers in those rooms to power those speakers; the Main Zone of the receiver remains 11.4-channel. The volume of Zone 3 can be controlled by the Denon receiver using either configuration or from your add-on amplifier when using the line-output.
- Compatible Sources:
- Optical/Coaxial digital inputs (2ch PCM only)
- Analog Audio Inputs (including Phono)
- AM/FM Tuner (cannot select different stations for each zone)
- USB & Bluetooth Audio (cannot select USB & Bluetooth in separate zones)
- HEOS Music Apps (including Pandora, Tidal, Amazon, and more); cannot select different HEOS music apps for each zone
- Network Sources (including TuneIn Internet Radio, Spotify Connect, AirPlay, & DLNA); cannot select two different network sources in multiple zone.
- Incompatible Sources:
- HDMI Audio/Video
- Analog Video
- DSD audio files
All Zone Functionality: The Denon AVR-X6800H offers an All Zone TV Audio and All Zone Stereo mode that allows you to listen to the same audio/video source in the Main Zone, Zone 2, and/or Zone 3.
- All Zone TV Audio: The All Zone TV Audio feature lets you play the same audio source as your TV in the Main Zone in Zone 2 and/or Zone 3 without losing fully discrete surround sound in the Main Zone. Enjoy fully discrete audio such as Dolby Atmos in the main zone for a completely immersive experience, while playing the same source in the second and/or third zone. The AVR-X6800H supports both HDMI and digital optical/coaxial sources for your second or third zone when ""All Zone TV Audio"" is active.
- All Zone Stereo: The All Zone Stereo function allows you to enjoy the AV receiver's Main Zone audio source in Zone 2/Zone 3 simultaneously (regardless of input audio signal types - analog, digital [including HDMI ARC/eARC], or wireless). During the All Zone Stereo mode, only the ""Multi Ch Stereo"" and ""Stereo"" sound modes can be selected. You will have independent volume control in each zone. All Zone Stereo mode is useful when you want to enjoy the same music at the same time in multiple rooms during a get together or party.
HEOS Wireless Multiroom Audio: Built-in HEOS technology enables the AVR-X6800H to become part of the HEOS wireless multi-room audio eco-system, allowing you to stream and control all of your local and online music effortlessly from anywhere in your home with the HEOS App on your compatible Apple iOS or Android mobile device over a wireless WiFi network connection. The HEOS system is a true multi-room audio system that automatically synchronizes audio playback between multiple HEOS devices so that your music (up to 24-bit/192kHz Hi-Res audio) coming from different rooms is perfectly in sync and always sounds amazing. You can play the same audio source in every room or any combination of rooms you choose, including a different song in every room.
- Systems & Groups: The HEOS wireless multi-room sound system by Denon can support up to 32 HEOS speakers, receivers, amplifiers, and/or pre-amplifiers (all sold separately) on a single wireless network (IEEE 802.11ac; 2.4/5GHz). You can join or group up to eight individual HEOS devices into a group that function as if they were a single source. The HEOS eco-system is flexible enough where you can create up to 16 Groups (2 HEOS devices per Group). You can easily group 16 rooms together with Party Mode by simply using a ""pinch"" gesture.
- Compatible Sources: The receiver's input sources, HEOS music apps, and local network content can be distributed through a HEOS multi-room audio system. However, you cannot distribute an input source (analog, HDMI, optical/coax, USB, Bluetooth, tuner) that is different than the main zone of the AV receiver (this is a change from previous HEOS enabled AV receivers).
- Receiver's analog inputs & AM/FM Tuner
- HDMI (including eARC) and optical/coax digital inputs; will downmix multi-channel audio sources to 2ch (receiver's main zone will retain multi-channel audio decoding)
- TuneIn Internet Radio & Spotify Connect
- HEOS music apps (including Amazon, Pandora,Tidal, and more)
- Windows PC & DLNA music servers
- Bluetooth & USB audio (AirPlay 2 is not supported)
- Music libraries stored on your Apple iOS or Android mobile device.
Note: The Denon AV receiver only supports a single HEOS music stream. If you desire a second HEOS music stream through the receiver's multizone output, you will need to connect the HEOS Link to one of the AV receiver's analog inputs.
HDMI Monitor 2: The receiver's HDMI monitor 2 output lets you send the same HDMI audio/video input signal that is being played in the main zone to a second zone (video is output at the resolution supported by both TVs). The HDMI monitor 2 output does not offer HDMI upscaling. The HDMI monitor 2 does not support the output of analog video inputs.
App, Voice, & Remote Control
IR Remote: The Denon AVR-X6800H comes with an IR remote for wireless operation of the AV receiver. The AVR-X6800H's remote can also be used to control select external audio/video components connected via HDMI which support HDMI control. The receiver can even be controlled by your HDMI connected Smart TV.
- HDMI-CEC: HDMI CEC allows you to link operation of the receiver with other audio/video components (like your TV, Blu-ray player, or satellite/cable box) that are connected via HDMI. Linked functions include Power On/Off, which turns the receiver On or Off when you power on or off an HDMI CEC connected component; and Source Switching, which automatically switches the receiver to the input of the HDMI CEC component that has begun playback. The HDMI CEC function can be disabled, if your prefer. Not all HDMI CEC compatible devices will function in the same way.
- Smart TV Control: You can even c
HEOS App: You'll need to download the HEOS App (for Apple iOS and Android OS) onto your compatible Apple iOS or Android mobile device to enjoy HEOS functionality through the AVR-X6800H receiver. Using your compatible mobile device and the HEOS app, you can setup, browse, explore, and control HEOS system right in the palm of your hand, from anywhere in your home. Your compatible Apple iOS or Android device must be connected to the same home wireless (WiFi) network as the AV receiver and your entire HEOS system. The HEOS app consists of 4 control screens.
- Settings: The ""Settings"" screen enables you to connect one or more HEOS speakers, receivers, amplifiers, and/or pre-amplifiers to your home's wireless network.
- Rooms: From the app on your Apple iOS or Android device, you can select which rooms you want playing. You can play the same music in multiple rooms by grouping rooms together, or you can listen to a different source in each room.
- Music/Sources: You can select what music and which source you want to listen to from the app. Choose from online music services like Pandora, Spotify, TuneIn, Tidal, etc.; your music library on your Apple iOS or Android device, Windows PC/DLNA server, or USB thumbdrive; analog, digital, and HDMI inputs; as well as Bluetooth. You can also select music from Playlists you've created, Favorites you've saved, and your recent listening History.
- Now Playing: The ""Now Playing"" screen displays song, artist, and album information; along with Album Art. You also get basic playback controls like Play/Pause and Previous/Next Track, plus Volume controls Up/Down and Mute. In addition the ""Now Playing"" screen functions unique to the selected online music service or music library.
Alexa Compatible: HEOS and Amazon Alexa customers can now enjoy the convenience of Alexa voice control plus high-quality wireless home audio. In addition to controlling your HEOS components with the HEOS app on your mobile device or tablet, you can now control them with Amazon Alexa voice technology and an Amazon Alexa device (such as the Echo or Echo Dot, sold separately). Your HEOS components and the Alexa-enabled devices must be on the same network. You will also need to download the Alexa app (for Apple iOS or Android OS) onto your compatible Apple iOS or Android device. Voice control features include -
- Alexa voice commands include Volume (up/down, specific volume number, & mute); Playback (Play, Pause, Stop, Next, Previous, Resume); and Power on/off. And thanks to the latest firmware update, you can even use Alexa to switch inputs on HEOS enabled AV receivers and soundbars.
- You can group your HEOS-enabled devices using the HEOS app with an Alexa-friendly name. Once they are grouped, Alexa voice commands will control the group as a whole. If you want to play audio content from only one HEOS-enabled device in the group, you must ungroup the device within the HEOS app.
- You are able use voice commands to search for songs, albums and artists and even podcasts and internet stations from HEOS & Alexa compatible music apps - like Amazon Music, Pandora, TuneIn, iHeartRadio, Spotify Connect, & SiriusXM.
Google Assistant Support: Ask your Google Home, the Google app (for Apple iOS and Android OS), or other devices with Google Assistant built-in to control HEOS content across your listening environment. Once you start music in the HEOS app, you can ask the Google Assistant to control volume, play, pause, skip tracks, and more. Once you have grouped your HEOS-enabled devices using the HEOS app, you can use the Google Assistant and voice commands to control a group of HEOS devices as a whole. Make sure the unit has the latest HEOS software and firmware update installed.
- A future firmware update (no ETA) will allow you to use the Google Assistant and your voice to queue up music services, power on/off devices, switch inputs and more.
- Click here for more info on Google Assistant for HEOS.
Josh.ai Smart Home Voice Automation: An elevated voice agent for the high-end smart home, Josh.ai offers flexible voice control for nearly any aspect of your day-to-day experience and entertainment environment. Use voice commands to control the Denon receiver, online music services, thermostat, lights, home appliances, and more. Josh.ai requires additional specialized hardware that is sold and installed by custom integrators. The Josh.ai Home Intelligence app (for Apple iOS or Android OS device) is designed to give you complete system control once installed.
AVR Remote App: The new Denon AVR Remote App (for Apple iOS 12 and Android OS) lets you control the Denon AV receiver using your compatible Apple iOS or Android OS mobile device. From this free app on your compatible Apple iOS or Android device, you'll be able to control the Denon AV receiver's basic functions; such as power, volume, input, surround modes, and other settings. You'll also be able to control separate Zones of the receiver, as well as navigate the AV receiver's network and Internet content from the app. In addition, you get unique features likes a landscape orientation control screen for tablet devices, the ability to create playlists, and control over a Denon Blu-ray player.
- Landscape Orientation Control Screen: With a landscape orientation control screen for tablet devices, you can easily browse and navigate through your network music services or personal digital music collection with ease, and at the same time view now-playing information and cover art all on a single screen.
- Create Playlists: The app's playback screen allows you to easily build your own personal music playlists on the fly with the ability to Drag & Drop files into your queue, or tap to ""Play Now"", ""Play Next"", ""Play Next and Replace Queue"" or ""Add to End of Queue"". You can then save your queue as a playlist for easy recall.
- Denon Blu-ray Player Control: The app allows control over Denon Blu-ray (DBT-xx13 series) that are connected to the AV receiver via HDMI.
Note: This AV receiver is not compatible with previous year's older Denon Remote App.
Audyssey MultEQ Editor App ($19.99): Download the Audyssey MultEQ Editor App (for Apple iOS and Android OS) onto your compatible Apple iOS or Android device for further sound customization and detailed tuning to more precisely tailor the sound to your room and personal preferences. This app lets you view the speaker detection results to check correct installation, view before and after results of the Audyssey calibration making it easy to identify room problems, edit the Audyssey target curve for each channel pair to suit your tastes, adjust the EQ frequency adjustment range for each channel pair, switch between two high frequency roll-off target curves, enable/disable midrange compensation to make the vocal region brighter or smoother, as well as save and load calibration results.
Custom Integration: The AVR-X6800H is part of Denon's IN-Command series line-up of receiver, which is Denon's certification to custom installers that the receiver has advanced connectivity and control features often required for custom home integration and theater applications using premium control systems. These features include IP control, a RS232C jack for use with whole house control systems, remote in/out IR command control, and 12V trigger outputs.
- RS-232C Port: The RS-232C port is used for connection to an external whole-house control system, from companies such as AMX, Crestron, etc.
- Remote Jacks: The minijack input and output jacks are to be used with an optional IR repeater system (sold separately).
- 12V Trigger Outputs: The AVR-X6800H has three minijack outputs to send a 12-Volt DC turn-on signal to another component that accepts a 12V trigger, such as a power amplifiers in Zone 2 and Zone 3. The conditions under which the trigger output activates is programmable.
- IP Control: The receiver can be set up and operated by a home computer on the network via IP control, either via wired LAN connection or Wi-Fi, and also features Control4 SDDP (Simple Device Detection Protocol) certification for quick and easy integration with Control4 home automation equipment.
Crestron Connect Intelligence: By embedding Crestron Connect intelligence in the Denon AVR-X6800H, it allows for seamless communication with Crestron home automation solutions, giving installers a simplified home theater solution and homeowners complete control of their home entertainment system.
Remote Monitoring: In today's custom install environment, it's critical for integrators to provide quick, reliable assistance and service to their clients, even after the install is complete. To support this effort, the Denon AVR-X6800H AV receiver features ""OvrC"" and ""Domotz Pro"" remote system monitoring and management technology. These programs allow custom integrators to monitor the status of connected products and troubleshoot remotely from the office or on the go, reducing the time it takes to address the issue.
Convenience Features
Advanced OSD w/ Setup Assistant (via HDMI): With Denon's advanced on-screen menu and setup assistant, you can connect, configure, and use your home theater system with ease. The OSD and setup assistant features clear on-screen graphics and text that optimizes critical system settings for your particular home theater setup.
- The on-screen menu and setup assistant is required for initial setup and is only available through the receiver's HDMI output.
- The on-screen menu is only supported by the main HDMI monitor output (not the Monitor 2 output or Zone 2 monitor out).
Quick Select: On the AVR-X6800H's front-panel and remote, you'll find four Quick Select buttons that let you quickly choose from the most popular input sources (including HEOS Music). With Quick Select, the AVR-X6800H remembers not only your preferred inputs but also your preferred audio settings, so you can enjoy precisely tailored sound with each one.
Input Rename & Delete: The AV receiver will automatically rename its HDMI inputs to the connected devices' names using HDMI CEC (the HDMI Control function must be enabled). You can also manually change the display names (up to 16 characters) of analog, HDMI, and optical/coaxial digital input sources. If an input isn't being used, you can delete it from the display so you don't have to scroll past it when you change sources.
Lock Functions: To prevent accidental operation of the AV receiver, you can disable operation of the buttons on the front-panel. You can also disable the receiver's IR sensor to prevent accidental operation of the receiver from the remote control. You can even disable operation of only Zone 2 from the remote control.
Sleep Timer & Auto Standby: The Denon AV receiver features a programmable Sleep Timer and Auto Standby function. The Sleep Timer allows you to automatically set the power to standby after a predetermined amount of time has passed; set the sleep timer up to 120 minutes in 10 minute increments. The unit enters Standby mode automatically when no commands are sent to the unit for the set time (15/30/60 minutes). Before it enters the standby mode, ""Auto Standby"" is displayed on the front-panel display of this unit and the on-screen menu.
ECO Mode: This receiver is equipped with an ECO Mode function that allows you to enjoy music and movies while reducing the power consumption during use, Eco mode adjusts the maximum power available according to the volume level selected to reduce power consumption.
Personal Memory Plus: For each input, the receiver automatically memorizes the settings for input mode, surround mode, HDMI output mode, audio delay, etc. When the input source is switched, the settings last used for that source are automatically recalled. The surround parameters, tone control settings, and playback levels for the different output channels are memorized for each surround mode.
Protection Circuit: This is a function to prevent damage to components within the power supply when an abnormality such as an overload, excess voltage, or over-heating occurs. In this unit, the power indicator blinks and the unit enters standby mode when an abnormality occurs.
Software Updates: Using the receiver's network/internet connection, you can check for and update the latest firmware from the online Denon server. You can also set the receiver to automatically download the latest firmware and software updates when it is in standby mode.
